[Aymericr]

What does this PR do?

Localizes the dormer, skylight and solar panel inspectors. Part of #621. main (ac2ba6e, with #1180–#1182, #1186 and #1187) is merged in with normal merge commits. There are two, because #1186 landed after the first. The compiled en and en-XA catalogs and the literal baseline were regenerated with i18n:extract, i18n:literals update and i18n:compile. i18n/pseudo-surfaces.ts merged cleanly and keeps all 40 surfaces once. Reviewed entries stay at 85 per locale, and release-check finds no draft compiled in. Stored scene data is unchanged.

• Option arrays become lazy descriptors:

  • dormer roof type, shed high side and section;
  • skylight type cards;
  • solar panel preset cards.

  The cards wrap their labels instead of truncating them.

• Dormer window rows:

  • "Window {number}";
  • "Edit {name}" and "Move {name}" as the icon buttons' accessible names;
  • one summary message for the face and size ("{face} · {width} × {height} m"). The face was the raw enum shown capitalised; it is now an ICU select. Sizes use formatFixed instead of toFixed.

• Preset names. Skylight types and solar panel presets are translated at display time. Core's SKYLIGHT_TYPE_PRESETS and SOLAR_PANEL_PRESET_LABELS stay English.

• Solar panel. The auto-fit message ("Setbacks too large to fit a panel.") is translated, and the panel sizes use formatFixed.

• Audit. New dormer-panel, skylight-panel and solar-panel-panel surfaces. They run on the furnished project with a dormer, a skylight and a solar panel seeded on its roof segment.

• Catalogs. 100 new messages. zh-CN, fr, es and ja drafts are fuzzy with Review: required, so they show English until reviewed. The literal baseline drops by 93, from 951 on main to 858.

How to test

1. bun run i18n:check passes after the merge, with 3,095 entries per locale awaiting review. bun scripts/i18n.ts release-check --base origin/main passes too.
2. Run bun dev with ?lang=en-XA. Select a dormer (and its Windows section), a skylight and a solar panel: each inspector is bracketed and accented, and the cards wrap.
3. Run bunx turbo run build --filter=@pascal-app/nodes, then bun run i18n:pseudo-audit -- dormer-panel skylight-panel solar-panel-panel: all three pass. I ran this.
4. Tests I ran after the merge, with core and nodes rebuilt first:
   • packages/nodes: 5,028 pass, 1 skip.
   • packages/editor bun test src: 2,704 pass.
   • apps/editor bun test lib: 74 pass.
   • bun test scripts/: 131 pass.
   • The editor, nodes and app type checks are clean, and bun run check reports no errors.

Still English after this PR

• Tool copy. The dormer, skylight and solar panel placement tools' preview names and HUD.
• Remaining inspectors: vents (box, ridge, turbine, eyebrow, cupola), fences and MEP, which are in [Maintainer] i18n: migrate the vent, fence and MEP inspectors #1185. Construction dimension and block also remain.

Screenshots / screen recording

en-XA, captured by i18n:pseudo-audit (UTC, metric). The images are served from the image-only branch cursor/i18n-audit-screenshots-8160, which is never merged.

Dormer:

Skylight (type cards wrap):

Solar panel:

Checklist

• I've tested this locally with bun dev
• My code follows the existing code style (run bun check to verify)
• I've updated relevant documentation (if applicable)
• This PR targets the main branch



---

Note

Low Risk
UI copy and translation catalogs only; inspector behavior and scene schema are unchanged aside from display formatting.

^{Reviewed by Cursor Bugbot for commit 17a851c. Bugbot is set up for automated code reviews on this repo. Configure here.}

[chatgpt-codex-connector]

Codex Review Summary

This comment shows the latest Codex review activity on this pull request.

Review	Status	Commit	Review trigger
📝 Code Review	🔄 Running since 2026-10-27T16:48:47.047711Z	e52693e	PR opened

ℹ️ About Codex in GitHub

Your team has set up Codex to review pull requests in this repo. Reviews are triggered when you

• Open a pull request for review
• Mark a draft as ready
• Comment "@codex review" or "@codex security review".

Codex reacts with 👀 while any review is running, comments if it has suggestions, and reacts with 👍 once all reviews finish with no findings.

[Aymericr]

Tooling cross-review at e52693e: APPROVE

No P0/P1/P2.

• Stored data: dormer, skylight and solar-panel copy is display only. Solar presets show PRESET_CARDS messages, and core's SOLAR_PANEL_PRESET_LABELS stay English (the English messages match). The auto-fit message is UI state only. Nothing translated reaches updateNode or MCP.
• Numbers: dormer window and skylight sizes move from toFixed(2) to formatFixed(..., 2, locale), which doesn't group, so English output is unchanged. No # plurals.
• Catalogs: +100 entries per locale, all fuzzy with Review: required. Reviewed stays at 85 per locale and drafts are 2626 for each locale.
• No Security areas are touched.

Findings

• P3: once [Maintainer] i18n: editor-side inspector panels and 3D overlay scope #1180 merges, only the compiled en/en-XA messages.ts will conflict. Re-run i18n:extract after rebasing. literal-baseline.json also conflicts with [Maintainer] i18n: migrate the vent, fence and MEP inspectors #1185.

Checks run locally (Node 22; core and nodes dist rebuilt at this head):

• Tests: editor 2704 pass; nodes 5026 run, 0 fail; scripts/i18n*.test.ts 56 pass.
• tsc clean for editor and nodes. Biome clean.
• i18n:check PASS, catalogs in sync. release-check --base origin/main shows no reviewed regression and no draft compiled in. i18n-literals check reports no new literals.

CI at this SHA: Changed paths, quality, cli-smoke and Cursor Bugbot all succeeded.

[Aymericr]

Tooling cross-review at 17a851c: APPROVE

Delta review since the e52693e approval:

• Parents check out: 68cafd8 = e52693e + b41339b (main, [Maintainer] i18n: migrate the column, chimney and elevator inspectors #1182), and 17a851c = 68cafd8 + ac2ba6e (main, Agents: units in author_scene and shared unit tools; opening frames follow the wall #1186). Both are normal merges, with no rebase.
• A clean local merge of e52693e with ac2ba6e conflicts only in the compiled en and en-XA messages.ts packs. Once those are taken from the head, the merge tree is identical to 17a851c (empty diff).
• A fresh i18n:extract, i18n:compile and i18n-literals update leave git status clean, and i18n:check passes.
• pseudo-surfaces.ts has 40 surfaces with no duplicate names (dormer-panel, skylight-panel and solar-panel-panel were added).
• The literal baseline goes from 951 to 858. That drop of 93 is exactly dormer (4+2+11+21), skylight (33) and solar-panel (22). The allowlist, scripts/ and .github are unchanged versus main, and the PR adds no i18n-ignore.
• 85 strings are reviewed, the same as main (3180 messages, 3095 awaiting review per locale). release-check --base origin/main is clean (exit 0).
• On Node 22, after rebuilding core and nodes: nodes 5,028 pass (1 skip, 0 fail), editor 2,704 pass (0 fail), and check-types passes (14/14).
• quality, cli-smoke, Changed paths and Cursor Bugbot are all green at this head. The PR is mergeable/clean against main ac2ba6e.

Nit, not blocking: pseudo-surfaces.ts now has two separate imports from ../packages/core/src/schema. They could be folded into one.
